| Shell and Seal Materials |
PVC, epoxy resins |
| Membrane Material |
PAN/PVC |
| Molecular Weight Cut off (dalton) |
50.000 |
| Effective Membrane Area |
4,8 m² |
| Hollow Fiber Id/od Size |
1.0 mm / 1.6 mm |
| Max Operation Pressure |
0,3 Mpa |
| Suggest Operation Pressure |
<0,2 Mpa |
| Max Transmembrane Pressure |
0,3 Mpa |
| Backwash Pressure |
0,05-1 Mpa |
| Produces Water Pollution Index (SDI 25) |
<3 |
| Intitial Flux |
1 m³/h |
| Desing Flux |
40-150L/m²/h |
| Operating Mode |
Cross flow or dead-end flow |
| Bacteria Removal Rate |
>4log |
| Permeate Turbidity |
<0,1NTU |
| Operating Temperature |
5-40ºC |
| PH Range |
2_10 |
